Product introduction of Modular curtain wall :
Etaifeng's Modular curtain wall is a type of building facade primarily composed of glass panels. It's called modular because Modular curtain wall system is divided into independent unit modules. This modular structure makes installation and maintenance very convenient; it's prefabricated in the factory and can be directly assembled on-site.
Modular curtain wall system boasts very high precision, excellent airtightness and watertightness, and its modular design and replaceable nature make it ideal for the facades of high-rise buildings and office buildings. Unlike traditional curtain walls, Modular curtain wall system completes most of the assembly in the factory, requiring only hoisting and fixing on-site, significantly shortening the construction cycle and improving overall quality control.
Product advantages of Unitized Curtain Wall system:
All Unitized Curtain Wall system units are manufactured and assembled in the factory, ensuring high precision and minimal error, resulting in faster and safer on-site installation. Unitized Curtain Wall system's modular hoisting design simplifies on-site operations, making it particularly suitable for high-rise and super high-rise projects, reducing external installation time and enhancing safety.
Superior Sealing Performance
Unitized Curtain Wall systems far surpass traditional curtain walls in sealing performance. Each Unitized Curtain Wall system unit undergoes triple sealing treatment in the factory—including silicone structural adhesive, EPDM sealing strips, and a hollow drainage system—ensuring that air, moisture, and dust cannot penetrate. All sealing processes are completed in a temperature-controlled, dust-free workshop, avoiding leakage problems caused by climate, dust, or improper operation during on-site construction. Through these complex sealing treatments, Modular curtain wall system maintains excellent airtightness and watertightness even in extreme climates, making it ideal for use as a building facade.
Modular Unit Design of Modular curtain wall system:
Modular curtain wall system employs a highly modular structural concept, pre-assembling glass, aluminum frames, insulation layers, and sealing systems into independent unit modules in the factory. On-site installation only requires hoisting and assembly, allowing for rapid large-area installation of Unitized curtain wall glazing units. This design not only greatly improves construction efficiency and reduces human error but also results in a smoother, more precise, and aesthetically pleasing overall facade. Furthermore, subsequent maintenance and replacement are more convenient—each Modular curtain wall system unit can be disassembled independently, avoiding large-scale construction and saving time and costs.
Key Performance Indicators of Unitized curtain wall glazing:
| Item | Parameter range: |
| Unit Dimensions | ≤ 1500mm × 3000mm |
| Curtain Wall Thickness | 150mm – 300mm |
| Air Tightness | ≤ 0.5 m³/(m·h) |
| Water Tightness | ≥ 700 Pa |
| Wind Pressure Resistance | ±5000 Pa |
| Materials Available | Glass / Aluminum Plate / Stone / Composite Panel |
Installation and Maintenance Services of Unitized curtain wall glazing:
Etaifeng provides full technical support for Unitized curtain wall glazing units, from on-site hoisting guidance and sealing inspection to post-installation maintenance training, all handled by a professional team. During the installation phase, we provide precise installation plans based on the project site conditions to ensure each Unitized curtain wall glazing unit is safely and efficiently installed. After project delivery, we also provide systematic maintenance guidance and training to help clients master the key points of daily inspection and maintenance, extend the service life of the curtain wall, and ensure that the building facade remains in optimal condition for a long time.
Factory Production Management of Unitized curtain wall glazing:
Unitized Curtain Wall system units adopt a fully factory production management model. From raw material testing, profile processing, glass assembly to sealant injection, all steps are completed in a controlled environment. This not only ensures the consistency and high precision of each Unitized Curtain Wall system unit but also effectively avoids safety hazards caused by on-site construction errors. Through standardized and modular production processes, Unitized Curtain Wall system unit quality is more stable and installation efficiency is higher, truly achieving a balance between high quality and high efficiency.
FAQs:
1. Why does Modular curtain wall system offer superior sealing performance?
Each Unitized Curtain Wall system sealant undergoes sealing compounding and structural assembly in the factory, ensuring a more controllable sealing environment and more stable quality. It also utilizes high-performance silicone structural adhesive and EPDM sealing strips to achieve superior airtightness and watertightness.
2. What types of buildings is Modular curtain wall system suitable for?
Unitized curtain wall glazing is suitable for super high-rise buildings, complex curved curtain walls, and projects with high requirements for airtightness and watertightness, such as high-end office buildings, hotels, airports, and convention centers.
3. Is Unitized curtain wall glazing easy to transport and install?
Each Unitized curtain wall glazing sealant is designed with standardized dimensions and can be transported as a whole package. On-site installation can be quickly completed through hoisting, positioning, and assembly, saving time and labor.
